Behind mobile crushing units place energy-saving horizontal aggregate vibrating screen sorting machine

The ability to process both dry and wet feed material makes our Horizontal Vibrating Screen exceptionally versatile for aggregate washing circuits where dewatering capability matters as much as sizing accuracy. When integrated with primary jaw crushers and cone crushers this mining vibrating screen completes a fully balanced comminution circuit producing cubical aggregate meeting strict construction specifications. For quarry owners seeking a gravel screener that handles fluctuating feed rates without sacrificing separation precision this vibrating screening machine delivers consistent performance.

Tel: +86 13176981712

WhatsApp: +86 13176981712

E-mail: info@tfindustry.com

Products Specifications

Model	Number of Layers	Screen Size (L×W) (mm)	Screen Inclination (°)	Feed Size (mm)	Capacity (t/h)	Power (kW)	Double Amplitude(mm)
1MLH1230	1	1200*3000	0	≤300	20-80	5.5	8-10
2MLH1230	2	1200*3000	0	≤300	30-100	7.5	8-10
2MLH1545	2	1500*4500	0	≤300	40-160	15	8-10
3MLH1545	3	1500*4500	0	≤300	50-180	15	8-10
2MLH1860	2	1800*6000	0	≤400	100-300	22	8-10
3MLH1860	3	1800*6000	0	≤400	100-300	22	8-10
2MLH2160	2	2100*6000	0	≤400	120-720	30	8-10
3MLH2160	3	2100*6000	0	≤400	120-720	30	8-10
2MLH2460	2	2400*6000	0	≤400	150-800	37	8-10
3MLH2460	3	2400*6000	0	≤400	150-800	37	8-10
2MLH3080	2	3000*8000	0	≤500	180-900	22*2	8-10
3MLH3080	3	3000*8000	0	≤500	200-1000	30*2	8-10

Horizontal Vibrating Screen

Horizontal structure ensures smooth material flow, high precision & large capacity.
Dual-motor self-synchronous vibration for balanced operation and anti-clogging.
Multi-deck options realize multi-grade separation in one machine to save cost.
Wear-resistant mesh & flexible dampers, low breakdown rate and easy maintenance.

Applications

◆ Mining: Ore grading, pre-screening, and tailings processing

◆ Aggregate Production: Stone classification, sand screening, and aggregate washing lines

◆ Construction: Material grading for concrete batching plants and road construction

◆ Coal Industry: Dry/wet screening of coal and gangue separation

◆ Quarry & Crushing Plants: Multi-stage material classification for crushing lines

Key Configurations

◆ Custom configurations available upon request.

◆ Standard explosion-proof vibrating motors

◆ Optional high manganese steel / PU / stainless steel screen panels
◆ High-quality composite rubber damping springs

◆ Thick plate integrally welded reinforced frame
